FEATURES
● 2.4GHz Multi-Protocol USB Transceiver
● Zigbee/Thread/Matter
● USB v2.0 full-speed
● TX power up to +20dBm
● Silabs EFR32MG21 Wireless SoC
● Over-The-Wire (OTW) update support
Runs 2 Protocols Simultaneously
● Dual-Protocol operation (Zigbee, Matter)
● Made for Home Assistant, adaptable for any case
● Futureproof Wireless Transceiver
● Low-risk bundle device for Gateway
The product supports Over-The-Wire (OTW) Firmware Update via the USB interface, which allows easy and quick firmware updates for both protocols. The device is an EFR32 Series 2 (Silicon Labs EZSP v8) adapter that will transmit at a power of +20 dBm. The drive supports full-speed USB 2.0 when plugged into the included USB extender.
Home Assistant will provide an Addon that will contact the Ember Stacks for Zigbee and Matter. We will provide updates to the firmware on a consistent basis that will provide the best user experience from a Zigbee/Matter Adapter. The USB Stick will be Plug and Play, tightly integrated with the Zigbee Home Automation integration allowing for a beginner-friendly experience.
Specifications:
● Support for Zigbee, Matter, and Thread
● Over-the-wire (OTW) firmware updates
● USB v2.0 full-speed
Technical Specifications:
● Supply:5VDC/upto150mA
● USB: v2.0 full speed (12Mbps)
● Bridge: USB to UART, Silabs CP2102N
Mechanical Specifications:
● Dimensions (LxWxH) : approx. 38.5 x 18 x 4,5mm
● Weight: 4g
RF Specifications:
● Transceiver: Silabs EFR32MG21
● Frequency: 2.4GHz
● Antenna: PCB
● TX Power : up to +20dBm
● RX sensitivity : -104dBm (250kbps)
● Protocols: Zigbee, Matter, Thread
● Stack: EmberZNet Serial Protocol
